Scope
- Applicable to establishing an artificial airway during clinical tracheotomy.
Features
- It is simple in operation, accurate in positioning, safe and controllable.
- It has less bleeding and fewer complications.
- It has two specifications: common type and sputum suction type, which are convenient to remove the secreta in the trachea and bronchus.
- It is easily tolerated by patients, and the patients can drink and eat, and care mouth more easily.
Product parameters(Unit: mm)
Model of common type | Specification of common type | Inner diameter | Outer diameter | Inflation diameter of cuff |
QK-Q/Z | 6.5 | 6.5 | 8.7 | 19/23 |
7.0 | 7.0 | 9.3 | 20/25 | |
7.5 | 7.5 | 10.0 | 21/26 | |
8.0 | 8.0 | 10.7 | 22/26 | |
8.5 | 8.5 | 11.3 | 23/26 | |
9.0 | 9.0 | 12.0 | 24/28 | |
9.5 | 9.5 | 12.7 | 25/29 | |
10.0 | 10.0 | 13.3 | 26/30 |
Model of sputum suction type | Specification of sputum suction type | Inner diameter | Outer diameter | Inflation diameter of cuff |
QKXT-Q/Z | 6.5 | 6.5 | 9.7 | 20/25 |
7.0 | 7.0 | 10.3 | 21/26 | |
7.5 | 7.5 | 10.9 | 22/26 | |
8.0 | 8.0 | 11.5 | 23/26 | |
8.5 | 8.5 | 12.2 | 24/28 | |
9.0 | 9.0 | 12.7 | 25/29 |
