Scope
- Applicable to minimally invasive single-port laparoscopic surgery, and serve as a channel for the surgical endoscope, forceps, scissors and other instruments to get in or out of the incision and the surgical operation.
Features
- With fewer openings, smaller wound and less bleeding, it can alleviate postoperative pain.
- It has high operational flexibility, good sealing and gas barrier property.
- It is equipped with a silicone fixing ring to stabilize the incision and extend the field of view.
- It can achieve low incision infection rate and quick recovery.
Product parameters(Unit: mm)
Model & specification | Incision protective cover | Channel height | Note | ||
Outer diameter of outer ring | Outer diameter of built-in ring | ||||
GA-A1-3 | 60 | 70 | 150 | No pull ring | Puncture cannula and Incision protective cover Embedded connection |
GA-A1-4 | 60 | 70 | 150 | ||
GA-A2-3 | 80 | 90 | 150 | ||
GA-A2-4 | 80 | 90 | 150 | ||
GA-A3-3 | 60 | 70 | 150 | Pull ring | |
GA-A3-4 | 60 | 70 | 150 | ||
GA-A4-3 | 80 | 90 | 150 | ||
GA-A4-4 | 80 | 90 | 150 | ||
GA-B1-3 | 75 | 75 | 150 | No pull ring | Puncture cannula and Incision protective cover Locking connection |
GA-B1-4 | 75 | 75 | 150 | ||
GA-B2-3 | 75 | 75 | 150 | Pull ring | |
GA-B2-4 | 75 | 75 | 150 | ||
